Scientists have developed HydroSpread, a novel method for constructing gentle robots on water, with wide-ranging prospects in robotics, healthcare, and environmental monitoring.
Image a miniature robotic, no bigger than a leaf, gliding effortlessly throughout the floor of a pond, very similar to a water strider. Sooner or later, machines of this scale could possibly be deployed to observe air pollution, collect water samples, or discover flooded zones too hazardous for individuals.
On the University of Virginia’s School of Engineering and Applied Science, mechanical and aerospace engineering professor Baoxing Xu is engaged on a solution to make such units a actuality. His staff’s newest research, printed in Science Advances, unveils HydroSpread, a fabrication method unlike any before it. The approach enables researchers to create soft, buoyant machines directly on water, a breakthrough with applications that could range from medical care to consumer electronics to environmental monitoring.
Previously, producing the thin and flexible films essential for soft robotics required building them on solid surfaces such as glass. The fragile layers then had to be lifted off and placed onto water, a tricky procedure that frequently led to tearing and material loss.
HydroSpread sidesteps this issue by letting liquid itself serve as the “workbench.” Droplets of liquid polymer could naturally spread into ultrathin, uniform sheets on the water’s surface. With a finely tuned laser, Xu’s team can then carve these sheets into complex patterns — circles, strips, even the UVA logo — with remarkable precision.
From Films to Moving Machines
Using this approach, the researchers built two insect-like prototypes:
- HydroFlexor, which paddles across the surface using fin-like motions.
- HydroBuckler, which “walks” forward with buckling legs, inspired by water striders.
In the lab, the team powered these devices with an overhead infrared heater. As the films warmed, their layered structure bent or buckled, creating paddling or walking motions. By cycling the heat on and off, the devices could adjust their speed and even turn — proof that controlled, repeatable movement is possible. Future versions could be designed to respond to sunlight, magnetic fields, or tiny embedded heaters, opening the door to autonomous soft robots that can move and adapt on their own.
“Fabricating the film directly on liquid gives us an unprecedented level of integration and precision,” Xu said. “Instead of building on a rigid surface and then transferring the device, we let the liquid do the work to provide a perfectly smooth platform, reducing failure at every step.”
The potential reaches beyond soft robots. By making it easier to form delicate films without damaging them, HydroSpread could open new possibilities for creating wearable medical sensors, flexible electronics, and environmental monitors — tools that need to be thin, soft and durable in settings where traditional rigid materials don’t work.
Reference: “Processing soft thin films on liquid surface for seamless creation of on-liquid walkable devices” by Ziyu Chen, Mengtian Yin and Baoxing Xu, 24 September 2025, Science Advances.
DOI: 10.1126/sciadv.ady9840
